ABM-FR60-FS200 is very rigid and strong, has very good compression and tensile strength.
Product Type | ABM- FR60- FS200 |
Nominal Density | 200 kg/m3 |
L x W* | 1000x600mm |
Thickness | 25mm ,50mm |
*Other size and thickness are available on request
Properties | Value | Unit | Standard | |
Thermal Conductivity Coefficient | 10℃ | 0.038 | W/(m?K) | EN 12667, ASTM C518 GB/T 10295 |
70℃ | 0.042 | |||
Fire Classification | Non- combustible Approval for A constructions | -- | IMOA.799(19) IMOA.754(18) | |
| Comporessive Strength | 60 | kPa | EN 1607 | |
Max Service Temperature | 650℃ | ℃ | ASTM C411 | |
Melting Point | ≥1000 | ℃ | ||
Water Vapor Absorption | ≤1.0 | % | ASTM C1104M | |
Sound Absorption | αw=0.8 | - | IS0 354 ISO11654 | |
Environment | Asbestos free, no CFCs、HCFCs or HFCs | --- | --- | |
The main application of ABM- FR60- FS200 products is used as core insulation with two layers of 30mm for A- 60 floating floor and 8 - 15 wall extension. The product is specially used where great load capacityrequired.
ABM has prepared a variety of facings for different products. In most cases, these facings can protect the product and enhance its performance. Customers can choose the facing base on personal demands.
The EGF-20210 is strong enough to protect insulation materials and prevent the dust spread to the environment with its high density
AG-10701 is composited with Aluminium foil and glass cloth, has good tensile strength, dust-free and nice outlook.
AL-30150 is a reinforced aluminum surface can provide the best solution on vapour barrier. It can protect the insulation materials and steel from vapour which will damage the insulation properties and cause the corrosion.
Contact us, ABM professional sales service team is ready for you .
