ABM-SR-MS80 is a semi-rigid board made from basalt and dolomite with better thermal, acoustic performance. It can be supplied with aluminium foil, aluminium glass cloth or glass cloth.
Product Type | ABM- SR- MS80 |
Nominal Density | 80 kg/m3 |
L x W* | 1200x600mm,1000x600mm |
Thickness | 50mm,100mm |
*Other size and thickness are available on request
Properties | Value | Unit | Standard | |
Thermal Conductivity Coefficient | 10℃ | 0.034 | W/(m?K) | EN 12667, ASTM C518 GB/T 10295 |
70℃ | 0.040 | |||
Fire Classification | Non- combustible | -- | IMOA.799(19) ASTM E136 | |
Max Service Temperature | Pipe 650℃ Facing 80℃ | ℃ | ASTM C411 | |
Melting Point | ≥1000 | ℃ | ||
Water Vapor Absorption | ≤1.0 | % | ASTM C1104M | |
Sound Absorption | αw=0.8 | - | IS0 354 ISO11654 | |
Facings | ALGC（AG1） GC( EG2) Reinforced alu foil（AL3） | -- | IMO A. 653(16) Low flame- spread | |
Environment | Asbestos free, no CFCs、HCFCs or HFCs | --- | --- | |
ABM-SR-MS80 is designed for high requirements on comfort,thermal and sound insulation
ABM has prepared a variety of facings for different products. In most cases, these facings can protect the product and enhance its performance. Customers can choose the facing base on personal demands.
The EGF-20210 is strong enough to protect insulation materials and prevent the dust spread to the environment with its high density
AG-10701 is composited with Aluminium foil and glass cloth, has good tensile strength, dust-free and nice outlook.
AL-30150 is a reinforced aluminum surface can provide the best solution on vapour barrier. It can protect the insulation materials and steel from vapour which will damage the insulation properties and cause the corrosion.
Contact us, ABM professional sales service team is ready for you .
